UDL-16

UDL-16
UDL-16 - Image 2
UDL-16 - Image 3

UDL-16

€2.190,00 RRP incl. 19 % VAT

Expand your TRX as a QO-100
 Satellite Earth Station

no Computer no Software no Soldering iron






QO-100 Bundle: IC-9700 + Hilberling UDL-16

The perfect entry into satellite radio – this perfectly matched combination of the Icom IC-9700 and Hilberling UDL-16 delivers maximum reception and transmission enjoyment on QO-100. The IC-9700 impresses with its brilliant spectrum scope and intuitive touch operation, while the Hilberling UDL-16 unlocks the full functionality for QO-100 with precise frequency conversion and professional RF engineering “Made in Germany.” Together, this bundle offers everything you need for a smooth start into the world of satellite communication.
Price on request – contact us now!
info@icomeurope.com / +49(0)-6104-98693-0





Category:

Description

• Supported Amateur Radio Bands 6 m / 2 m / 70 cm / 23 cm
Frequency Ranges 50.5-51.0 / 144.5- 145.0 / 432.5-433.0 / 1296.5- 1297.0 MHz
• 16 Band Combinations (RX/TX) switchable (internal Selector and Remote Control)
(4 x Simplex Operation and 12 x Duplex Operation via separate RX OUT)
• TX HF-VOX typ. 50 dB Dynamic with 3 dB Hysteresis I VHF/UHF Pin Diodes
• GPS-supported int. l O MHz OCXO Reference Signal incl. Output for TRX sync.
• TRX-lnput 25 mW- l O W PEP adjustable@ VHF/UHF I SSB / CW / Data
• TX-Output 20 W PEP @2.4 GHz/ 50 0 Low Pass Filter / RBW l 0 MHz
• Protection circuits against Overtemperature and SWR >3
• Data interface RS-485 Remote Control I Input PTT Signal
• Input active GPS Antenna for int. l O MHz Synchronisation ( Supply Voltage +3.3 V DC )
• Input 12 – 16 V DC / l O A I alternative: Remote Power Supply via TRX Coax Cable
• Protection Class IP67 1 lndoor / Outdoor Installation
• Weight 3.3 kg I Dimensions 260 x 150 x 125 mm (B x T x H)
